Detailed Specifications: Type Type Digital AF/AE SLR Recording Medium CF Card Type I and II, SD/SDHC Memory Card (1 slot each), and/or External media (USB v.2.0 hard drive, via optional Canon WFT-E2A transmitter) Image Format 1.11 x 0.74 in./28.1 x 18.7mm (APS-H size sensor) Compatible Lenses Canon EF, TS-E, and MP-E lenses (except EF-S lenses) Lens Mount Canon EF mount Lens Focal Length Conversion Factor* 1.3x Image Sensor Type High-sensitivity, high-resolution, single-plate, CMOS sensor Pixels Approx. 10.10 megapixels Total Pixels Approx. 10.70 megapixels Aspect Ratio 3:2 (Horizontal:Vertical) Color Filter System RGB primary color filters Low-pass Filter Fixed position in front of the CMOS sensor Recording System Recording Format DCF 2.0 (Exif 2.21): JPEG, RAW and RAW+JPEG simultaneous recording possible. Multiple options for recording images on two memory cards, and onto compatible external USB hard drives (via optional Wireless File Transmitter WFT-E2A) Image Format JPEG, RAW (Canon .CR2) File Size (1) JPEG/Large: Approx. 10.1MB (3,888 x 2,592), (2) JPEG/Medium 1: Approx. 8.0MB (3,456 x 2,304), (3) JPEG/Medium 2: Approx. 5.3MB (2,816 x 1,880), (4) JPEG/Small: Approx. 2.5MB (1,936 x 1,288), (5) RAW: Approx. 10.1MB (3,888 x 2,592), (6) sRAW: Approx. 2.5MB (1,936 x 1,288) Folders Can be manually created by user, and freely selected for subsequent images. File Numbering (1) Continuous numbering (2) Auto reset (3) Manual reset (the image numbering is reset to 0001, a new folder is created automatically) Color Space Selectable between sRGB and Adobe RGB Interface USB 2.0 Hi-Speed, mini-B port. NTSC/PAL for video output White Balance Settings Auto, Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash, five Custom WB settings (1-5), user-set Color Temperature (2,500~10,000K), five Personal White Balance PC-1 to PC-5 (Total 10 WB types) Auto White Balance Auto white balance, taken from imaging sensor Color Temperature Compensation White balance bracketing: Three consecutive images, Up to +/- 3 levels in 1-stop increments White balance correction: blue/amber bias and/or magenta/green bias +/- 9 levels; manually set by user, When blue/amber bias and magenta/green bias set with White balance correction, white balance bracketing cannot be set together during white balance correction Viewfinder Type Eye-level SLR with fixed pentaprism Coverage Approx. 100% horizontally and vertically Magnification 0.76x (-1 dpt with 50mm lens at infinity) Eyepoint Approx. 20mm Dioptric Adjustment Correction -3.0 to +1.0 diopter Mirror Quick-return half mirror (Transmission: reflection ratio of 37:63) Viewfinder Information AF (AF points, focus confirmation light), Exposure (metering mode, spot metering area, shutter speed, aperture, manual exposure, AE lock, ISO speed, exposure level, exposure compensation, exposure warning), Flash (flash ready, high-speed sync, FE lock, flash exposure level), Image (JPEG recording, RAW recording, shots remaining, white balance correction, memory card information), Battery check Depth-of-Field Preview Enabled with depth-of-field preview button; possible in Live View mode Eyepiece Shutter Built-in Autofocus Type TTL-AREA-SIR AF-dedicated CMOS sensor AF Points 19 cross-type AF points (plus 26 Assist AF points) AF Working Range EV -1 ~18 (ISO 100 at 73 degreesF/23 degreesC) Focusing Modes Autofocus (One-Shot AF, Predictive AI Servo AF), Manual Focus (MF) AF Point Selection Automatic selection; Manual AF point selection: 19 AF points, Inner 9 AF points (C.Fn III-9-1), Outer 9 AF points (C.Fn III-9-2) Selected AF Point Display Superimposed in viewfinder and on LCD panel AF-assist Beam None. Emitted by EX-series Speedlite or optional ST-E2 Speedlite Transmitter Exposure Control Metering Modes 63-zone TTL full aperture metering, (1) Evaluative metering (linked to all AF points), (2) Partial metering (approx. 13.5% of screen, at center), (3) Spot metering (approx. 3.8% of screen), Center spot metering, AF point-linked spot metering, Multi-spot metering (max. 8 spot metering entries), (4) Centerweighted average metering Metering Range EV 0-20 (ISO 100 at 73 degreesF/23 degreesC with EF 50mm f/1.4 USM lens, ISO 100) Exposure Control Systems Program AE (shiftable), Shutter speed-priority AE, Aperture-priority AE, E-TTL II program AE (Evaluative flash metering, Averaged flash metering), Manual ISO Speed Range Equivalent to ISO 100-3200 (in 1/3-stop or whole stop increments), ISO speed can be expanded to ISO 50 and 6400 (via C.Fn I-3)* Exposure Compensation Exposure Compensation (user-set): +/-3 stops in 1/3- or 1/2-stop increments. Auto Bracketing (AEB): 3 shots, up to +/- 3 stops, in 1/3 or 1/2 stop increments, in all exposure modes. Can be changed via C.Fn I-6 to 2, 5, or 7 shots. Bracketing order can be changed via C.Fn I-5. AE Lock Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved, Manual (user-set): By AE lock button in all metering modes Shutter Type Vertical-travel, mechanical, focal-plane shutter with all speeds electronically controlled Shutter Speeds 1/8000 to 30 sec. (1/3-stop increments), X-sync at 1/300 sec. (with EOS Speedlites; 1/250 maximum with other shoe-mount flashes, and up to 1/60 with studio strobes) Shutter Release Soft-touch electromagnetic release Self-timer 10 sec. delay, 2 sec. delay Remote Control Canon N3 type terminal External Speedlite EOS External Flash or Dedicated Speedlites E-TTL II autoflash with all EX Series Speedlites PC Terminal Provided; accepts third-party flash units with sync line voltages up to 250V maximum Drive System Drive Modes Single, silent, high-speed continuous (approx. 10 fps), low-speed continuous (approx. 3 fps), 10- or 2-sec. self-timer Continuous Shooting Speed Approx. 10 fps (at a shutter speed of 1/500 sec. or faster in all recording modes); fastest speed can be lowered if desired via C.Fn III-15 Max. Burst During Continuous Shooting JPEG: approx. 110 frames (Large/Fine, at standard level 8 compression setting), RAW: approx. 30 frames, RAW+JPEG: approx. 22 frames (Large/Fine) LCD Monitor Type TFT color, liquid-crystal monitor Screen Monitor size 3.0 in. Pixels Approx. 230,000 pixels Coverage Approx. 100% Brightness Control 7 levels provided Playback Image Display Format Single image, 4-image index, 9-image index, Jump, Magnified zoom (approx. 1.5x to 10x), Histogram, Auto rotate, Rotate, Live view: view image before shooting on LCD monitor; live histogram and live simulation of exposure level possible with C.Fn IV-16-1 Highlight Alert In the single image display and (INFO) display, over-exposed highlight areas will blink Image Protection and Erase Protection Single image, all images in a folder, or all images in the memory card can be protected or cancel the image protection Erase Single image, all images in a folder, all images in the memory card or check-marked images can be erased or unprotected. Direct Printing from the Camera Possible with compatible PictBridge-enabled printers Compatible Printers CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge compatible printers (via USB Interface Cable IFC-200U, included with camera kit) Settings Print quantity, style (image, paper size, paper type, printing effects, layout, date, file number), trimming Menus Menu Categories (1) Shooting (2) Playback (3) Setup, (4) Custom function/My Menu LCD Monitor Language 18 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Simplified/Traditional Chinese, Korean, Japanese) Power Source Battery One dedicated lithium-ion battery LP-E4, AC power can be supplied via the AC Adapter Kit ACK-E4 Number of Shots At 68 degreesF/20 degreesC: Approx. 0000, At 32 degreesF/0 degreesC: Approx. 000, The above figures apply when a fully-charged Battery Pack LP-E4 is used Battery Check Automatic Power Saving Provided. Power turns off after 1, 2, 4, 8, 15, 30 min. Back-up Battery One CR2025 lithium battery Dimensions and Weight Dimensions (W x H x D) 6.1 x 6.2 x 3.1 in./156 x 156.6 x 79.9mm Weight 40.7 oz./1,155g Operating Environment Operating Temperature Range 32-113 degreesF/0-45 degreesC Operating Humidity Range 85% or less
|
